Steel pole, galvanised inside and outside. Conical design. Height from ground level optionally 7000mm. Pole Ø at the bottom 168mm. Embedded base with 2 openings for cable entry, optionally with square flange plate. Separate embedded base on request. With inspection-door and C-rail for fuse-box. When equipped with ARINI light +, additional junction box for wiring of control leads. Arrangement of luminaire heads either single-sided, two-sided (180° shifted) or in 360° design. RAL Pearl-Metallic on request
Focus60 Accent Fire Rated downlight with black baffle for glare control and minimal ceiling trim. This product can accommodate the Lucent LED50 ONE GEN2 (90CRI) or LED50 ONE ULTRA (98CRI). This Fire Rated product was tested in a timber joist ceiling construction consisting of double thickness plasterboard ( 2 x 12.5mm) , wooden joists and (Egger) chipboard flooring.
Single emission lines for outdoor application. The warm white LED light source is composed of 18 powerled LEDs. The device body is made of aluminium 6060 and features a anodised black finish, processed by means of 15 µm anodizing; the diffuser is made of extra clear glass - tempered with a silk-screening treatment. The ingress protection degree is IP67; the total weight is of 2.8 kg. The power supply cable is included and features a 0.2 m length. The device features protection class I and can be floor-mounted with an outer casing, code 98725 (for concrete or masonry). Compliant with the EN 60598-1 standard and its specific provisions.
