Lightplane 2.5 is a compact and streamlined luminaire that provides direct, indirect or directindirect illumination from a suspended, wall or surface mounted channel. The fixture is available with several LED lamping options including multiple outputs and CCTs, tunable white and colour-changing RGB+White. A Low UGR option is available with a prismatic lens is also available.

Floodlight for outdoor installation on a façade/wall, with U shape fixing bracket allowing vertical adjustment of +90° / -40°. Phospho-chromatised and polyester powder coated die-cast copper-free aluminium base and head, tempered safety glass, moulded silicone gaskets, with screws in stainless steel. Built-in LED driver, with 1 COB CREE “CXB 1512” LED. IP66 rating.

The black powder-coated cast aluminum housing doubles as a heat sink, with a 0°-30° tilt and 850mm connection cable. It features a 360° rotatable fixing ring, expanding spring mounting, and an ERCO Casambi control gear. The high-power LED module includes a color mixer, collimating lens, and Darklight optical polymer lens with a 40° cut-off. Controlled via the Casambi app (BLE). Approved for emergency lighting (IEC/EN 60598-2-22). Protection Class II. Weight: 0.70kg.

Four universe Art-Net/sACN to DMX512 & RDM converter. All 4 ports are bidirectional and also support DMX512 to Art-Net/sACN conversion.
