APEX
WALLWASHER
OUTDOOR LIGHTING
WW4228_36W_10D

Rigid Wallwaher luminaire come with 3 different length, 348mm, 515mm and 1015mm. Various wattage and beam angle available. IP66

Specification
Power 36W/M
Color Temperature 3000K
Light Source Type LED
Lumen Output 3240LM/M
Finishing BLACK
IP Rating IP66
Color Rendering CRI 90
Driver ON/OFF DRIVER
See More
MEYER
FLOODLIGHT
OUTDOOR LIGHTING

Housing made of corrosion‑resistant die‑cast aluminum AlSi12, polyester powder coated by high‑quality and UV‑stabilized coating process, Colour: black ral 7021, all exterior parts are stainless steel, tempered safety glass, anti‑reflective coating from 1 side, dark screenprint, silicon gasket, closure with 3 stainless steel screws, mounting bracket: 2 drilled holes Ø 7 mm, spacing 30‑40 mm, 1 centre hole Ø 17 mm, tilt range: 180°, cable gland: M20, connecting terminal: 3 pole, precise PMMA optics, integral driver (AC/DC), CRI > 80, max 2 SDCM, service life L90/B10 > 50.000 h, Beam angle (fwhm): 35°, luminous flux: 2385 lm, wattage: 46 W, delivered lumens 52 lm/W, protection type IP67, protection class I, impact resistance IK08, windage area 0,025 m², dimensions: Ø 194 mm, width 124 mm, weight 2.8 kg. The modular luminaire design makes the replacement of components possible. The product meets the demands of the applicable EU guidelines and product safety regulations and bears the CE and ENEC marks. Customized solutions and modifications are possible: Special ral, db or ncs colours as polyester powder coat, luminaires in 2700 K and other colour temperatures and versions for high ambient temperature.

LINEALIGHT
SPOTLIGHT
OUTDOOR LIGHTING

Single emission projectors for outdoor application. The RGBW - 3000 K LED light source with a medium wide flood light distribution is composed of 1 powerled LEDs with CCT of RGB-W 3000 K. The device body is made of die-cast aluminium en ab - 46100 and features a grey finish, processed by means of open pore anodizing + powder coating; the diffuser is made of extra clear glass - tempered with a silk-screening treatment. The ingress protection degree is IP66; the total weight is of 1 kg.

LUCI
LED LIGHT BAR
INDOOR LIGHTING

Wall grazing LED light bar beautifully accentuate wall elements with new and powerful high CRI LED. Housing made of aluminium and polycarbonate material. Original optical lens with less scalloping and applicable for wide range of offset distances.

LINEALIGHT
PROJECTOR LIGHT
OUTDOOR LIGHTING
Single emission projectors for outdoor application. The warm white LED light source with a medium flood light distribution is composed of 1 arrayled LEDs. The luminaire body is made of aisi 316 steel and features a steel finish, processed by means of electropolishing; the diffuser is made of extra clear glass - tempered with a silk-screening treatment. The ingress protection degree is IP68,IK10.
