Recessed adjustable type downlight, aluminium housing, different types of beam angle.

Miniaturized lighting fixture Laser Blade XS Linear optical element with 10 cells (10 LEDs) Recessed lighting fixture with a radiant surface in die-cast zama, complete with springs for installation. Frame version with a perimeter trim. LED Single Chip High Power 2700K LED Color Rendering Index -CRI90- High-definition Opti Beam reflector in metallized thermoplastic material. WIDE FLOOD optics. Black polycarbonate raster with glossy surface (not painted). Product includes a DALI-2 dimmable.

The pendant luminaire SIGN from the familiy SIGN consists of aluminum-extruded profile. The article can be powder coated in 25 colours. The ballast is integrated and allows for an operation with 220-240V (50/60Hz). SIGN (# 410-1502) is dimmable via BUS. The luminaire with direct illumination and corresponds to protection class SK1 at IP20.

Housing made of corrosion‑resistant die‑cast aluminum AlSi12, polyester powder coated by high‑quality and UV‑stabilized coating process, Colour: black ral 7021, all exterior parts are stainless steel, tempered safety glass, anti‑reflective coating from 1 side, dark screenprint, silicon gasket, housing locked with a grub screw, ceiling mounting: 2 drilled holes Ø 4.5 mm, spacing 35 mm, cable gland: cable entry for recessed cable Ø 7‑10 mm , connecting terminal: 3 pole, highly efficient aluminum hybrid‑reflector with lens for narrow beam control , integral driver (AC/DC), CRI > 80, max 3 SDCM, service life L90/B10 > 50.000 h, Beam angle (fwhm): 6°, luminous flux: 326 lm, wattage: 5 W, delivered lumens 65 lm/W, protection type IP65, protection class I, impact resistance IK07, windage area 0,005 m², dimensions (L×H×W): 61 × 87 × 66 mm, weight 0.57 kg. The modular luminaire design makes the replacement of components possible. The product meets the demands of the applicable EU guidelines and product safety regulations and bears the CE mark. Customized solutions and modifications are possible: Special ral, db or ncs colours as polyester powder coat, luminaires in 2700 K and other colour temperatures and versions for high ambient temperature.
