Single emission downlights for indoor application. The warm white LED light source with a spot light distribution is composed of 1 powerled LEDs. The device body is made of die-cast aluminium en ab - 46100 and features a embossed black ral 9005 finish, processed by means of powder coating; the diffuser is made of uv resistant polycarbonate. The ingress protection degree is IP44; the total weight is of 0.128 kg. The power supply driver is not provided and is to be ordered separately. The power supply cable is included and features a 0.170 m length. The device features protection class III and can be ceiling-mounted, with a 35 x 35 mm hole (in plasterboard). Compliant with the EN 60598-1 standard and its specific provisions.

Round recessed downlight made of die-cast aluminium with black powder-coating finish (RAL 9005) and black reflector; System Power 8.5W; measurements Ø65mm x 74mm; ceiling cutout of Ø55mm with a narrow mounting trim; ceiling thickness 5-20mm; rotation 355° and pivot max. 30°; CCT 2700K with a System luminous flux of 520lm; high color rendering at an index of CRI90; after a lifetime of 50000h L80B10 min.

FUSION FF3

FF3-9302407F-BB

Square recessed ceiling downlight made of die-cast aluminium with black powder-coating finish (RAL 9005) and black reflector; ON-OFF Driver; LED 7W; measurement 98mm x 45mm; ceiling cutout of 90mm x 37mm with a narrow mounting trim; luminaire's weight is approximately 180g; CCT 3000K with an LED Output of 650lm; high color rendering at an index of CRI90; after a lifetime of 50000h min. 80% of the luminous flux with energy efficient OSRAM LED Chips; 5 years warranty; narrow beam characteristic with 24° beam angle; lighting perfectly suitable for reading, writing as well as computer and control work according to DIN EN 12464-1 (UGR<10); degree of housing protection according to DIN EN 60529 (IP20)

Single emission lines for outdoor application. The RGBW - 3000 K LED light source with a spot light distribution is composed of 12 powerled LEDs. Luminaire body is made of aluminium 6060 and features a anodised aluminumfinish, processed by means of 20 µm anodizing; the diffuser is made of extra clear glass - tempered with a silkscreening treatment. The ingress protection degree is IP67; IK10.
