Single emission lines for outdoor application. The warm white LED light source with a medium wide flood light distribution is composed of 12 powerled LEDs. The device body is made of aluminium 6060 and features a anodised aluminum finish, processed by means of 20 µm anodizing; the diffuser is made of extra clear glass - tempered with a silk-screening treatment. The ingress protection degree is IP68; the total weight is of 1.020 kg. The power supply cable is included and features a 0.250 m length. The device features protection class II and can be floor-mounted with an outer casing, code 99762 (for concrete or masonry). Compliant with the EN 60598-1 standard and its specific provisions.

Updated with low wattage high lumen LED series Available 4 different wattage variations Side bend dot-free flexible strip IP67, max custom length 2m for outdoor usage, up to 10m per circuit

IP69. IK10+. Stainless steel construction including PCS hardware. Safety glass lens, max. load 5 tonnes. Luminaire can be driven over at low speed. Silicone rubber gasket. Factory-sealed termination chamber with cable gland and 0.5 m of flexible PVC-free cable. Integral EC electronic converter. Advanced thermal management protects LEDs while optimising lumens output. Removable LED boards for upgrading. CAD-optimised optics for superior illumination and glare control. OLC One LED Concept. 20° tiltable and 355° rotatable. 1-10 V analogue dimming or DALI interface available on request. Luminaire installation blockout and sealable junction box included in supply.

The luminaire consists of aluminium profiles, cast aluminium and stainless steel Pole with laminated wood in accordance with DIN EN 14080 and aluminium Laminated wood made of finger-jointed pine slats Metal components are powder coated and painted Safety glass with optical structure Silicone gasket Reflector made of pure anodised aluminium Fixing of the light building element with anchorage unit 71 140 or screw-on base 70 833 for bolting onto a foundation (see accessories).
