MEYER
SURFACE MOUNTED DOWNLIGHT
OUTDOOR LIGHTING
8 321 046 059

Housing made of corrosion‑resistant die‑cast aluminum AlSi12, polyester powder coated by high‑quality and UV‑stabilized coating process, Colour: black ral 7021, all exterior parts are stainless steel, tempered safety glass, anti‑reflective coating from 1 side, silicon gasket, with grub screw, ceiling mount: 3 drilled holes Ø 5 mm on circular pitch Ø 84 mm, cable gland: Ø 7‑10 mm, recessed or surface mounted cable, connecting terminal: 3 pole, rotationally symmetrical aluminum reflector, highly efficient optics made of transparent thermoplastic for precise lighting tasks , integral driver (AC/DC), CRI > 80, Beam angle (fwhm): 31°, luminous flux: 1908 lm, wattage: 25 W, delivered lumens 75 lm/W, protection type IP65, protection class I, impact resistance IK08, dimensions: Ø 150 mm, width 180 mm, weight 2.1 kg. The modular luminaire design makes the replacement of components possible. The product meets the demands of the applicable EU guidelines and product safety regulations and bears the CE mark. Customized solutions and modifications are possible: Special ral, db or ncs colours as polyester powder coat, luminaires in 2700 K and other colour temperatures and versions for high ambient temperature.

Specification
Power 25W
Color Temperature 3000K
Light Source Type LED
Lumen Output 1908LM
Finishing DIE-CAST ALUMINUM
IP Rating IP65
Color Rendering CRI>80
Driver ON/OFF DRIVER
See More
PUK
DISPLAY LIGHT
OUTDOOR LIGHTING

Diam. 45 mm micro-projector for external use, ideal to light bushes, flowerbed and gardens in general. Body made in turned and anodized aluminum. In horizontal axis it can be oriented up to 30° down and up to 90° up. Remote 24V DC driver needed, with 1 x CREE “XPG2” LED. IP66 rating.

LUCE & LIGHT
ADJUSTABLE DOWNLIGHT
INDOOR LIGHTING

Esem Mid 1.1

recessed downlight for indoor applications; recessed (ceiling, wall, shelf); Power consumption: max 3W (3 power LEDs x 1W); Power supply: max 350mA; Lumen output at source: 309 lm (3000K, 350mA); Delivered lumen output: 220 lm (3000K, 350mA, 22°); 3 power LEDs, 1/4 ANSI BIN, 50 000h L95 B10 (Ta 25°C); LED colour: 2700K, 3000K, 4000K, 5000K; Optics: 11° tiltable ±20°, 22° tiltable ±20°, 30° tiltable ±20°, 20°x45° tiltable ±20°; CRI Colour Rendering Index: 80

CDN LIGHTING
RECESSED DOWNLIGHT
INDOOR LIGHTING


SIMES
FOOT LIGHT
OUTDOOR LIGHTING

Wall mounted luminaire. IP rating IP 65

WALKER is a wall recessed fitting designed to guarantee a wide distribution of light and directed downwards. Acid-etched toughened glass 4 mm thick. Colour rendering index CRI 90.
