Outdoor inground uplight anti-glare and double waterproof structure design.

Easy to hide and install without destroying the original environment. Nearly

zero distance against the wall, wash the wall evenly. Built-in modular

integrated lens with high light efficiency. Zero luminous depreciation at

3000hrs, long lifespan with low power consumption, 70%-80% energy-

saving and environmental friendly. Designed for versatile use in outdoor

lighting application.

Recessed luminaire applicable to the floor or ground, designed for fitting monochrome white LED sources, for illumination, adjustable optic, with DALI dimmable incorporated electronic control gear. The round frame has a diameter D200 mm the body and frame are made of AISI 304 stainless steel with sodiumcalcium extra clear glass, thickness 15 mm. Stainless steel body coated with black paint. The luminaire is secured to the outer casing by means of two TORXtype screws that ensure proper anchoring. Inclusive of LED circuit, methacrylate lens and black plastic cover. The ingress protection degree is IP67,IK09.

Inground walkover linear

module LED 3000K 220-240Vac ON-OFF

Inground walk over fitting. Recessing depth 95 mm. IP rating IP 65 IP67

Housing made of die‑cast aluminum AlSi12, polyester powder coated by high‑quality and UV‑stabilized coating process, Colour: black ral 7021, all exterior parts are stainless steel, tempered safety glass, anti‑reflective coating from 1 side, dark screenprint, silicon gasket, closure with 4 stainless steel screws, wall box: 2 drilled holes Ø 7 mm, spacing 110 mm, cable entry 7 – 10 mm, for recessed or surface mounted cable, tilt range: 200°, cable gland: M20, connecting terminal: 3 pole, highly efficient reflector, integral driver (AC/DC), CRI > 85, 2 SCDM, service life L90/B10 > 50.000 h, luminous flux: 2550 lm, wattage: 26 W, delivered lumens 98 lm/W, protection type IP67, protection class I, impact resistance IK08, windage area 0,035 m², dimensions (L×H×W): 184 × 70 × 184 mm, weight 3.4 kg. The modular luminaire design makes the replacement of components possible. The product meets the demands of the applicable EU guidelines and product safety regulations and bears the CE and ENEC marks. Customized solutions and modifications are possible: Special ral, db or ncs colours as polyester powder coat, luminaires in 2700 K and other colour temperatures and versions for high ambient temperature.
