The Nano Eyeconic Mini Trim Adjustable is an incredibly discreet recessed, directional downlight with a ø38mm bezel and features a beautifully sculpted anti-glare baffle. Unique, elegant small aperture. Easily interchangeable optics. Flawless finishes available on all components. 26° Tilt, 360° Rotation.

Projector for outdoor applications; surface mounted (ceiling, wall, ground, spike); Power consumption: 5W; Power supply: 24Vdc; Lumen output at source: 452 lm (3000K, 5W, CRI >90); Delivered lumen output: 284 lm (3000K, 34°, 5W, CRI >90); 1 high-intensity power LED, 3-step MacAdam, 50 000h L90 B10 (Ta 25°C); LED colour: 2700K; Optics: sharp 21°: SHARP optical system consisting of a plano-convex lens for an extremely welldefined light beam, combined with a high-quality technical filter; etc.

Narrow LED pitch suitable for limited space installation (10mm pitch, 16mm pitch. Small section W10mm * H4mm. 2 types of wattage (3.9W, 2.5W per meter). Customized length available up to 5m per roll.

Compatible with 100CLO, 100CLE and 100PLE series LED modules.Colour temperature options 2700K, 3000K, 4000K, 5000K, WarmDim. Colour rendering index 85 or 95. Up to 50,000 hours L80 lamp life with LM80 tested LED chip packages. Beam pattern options ClassicPRO 12, 20, 35, 60 Luminous flux 1063lm to 3000lm depending on LED module.Supplied with non-dimmable or phase0-10VDALI dimmable LED driver. Automated Thermal Protection System. ComfyEYE, reduced flicker percentage, Interchangeable LED module system, Optional colour and light effect filters, and honeycomb anti-glare louvre, For the latest specifications please refer to the website. The ingress protection degree is IP40.
