LINEALIGHT
SURFACE TRACKLIGHT
INDOOR LIGHTING
81636W30

Single emission projectors for indoor application. The warm white LED light source with a medium flood light distribution is composed of 1 arrayled LEDs. The device body is made of die-cast aluminium en ab - 46100 and features a embossed black ral 9005 finish, processed by means of powder coating. The ingress protection degree is IP20; the total weight is of 0.612 kg. The device features protection class II and can be ceiling-mounted. Compliant with the EN 60598-1 standard and its specific provisions.

Specification
Power 29W
Color Temperature 3000K
Light Source Type LED
Lumen Output 1836LM
Finishing BLACK
IP Rating IP20
Color Rendering CRI 98
Driver ON/OFF DRIVER
See More
LINEALIGHT
RECESSED DOWNLIGHT
INDOOR LIGHTING
Single emission downlights for indoor application. The warm white LED light source with a adjustable wall washer light distribution is composed of 8 powerled LEDs. The device body is made of die-cast aluminium en ab - 46100 and features a embossed black ral 9005 finish, processed by means of powder coating. The ingress protection degree is IP20; the total weight is of 0.36 kg. The power supply driver is not provided and is to be ordered separately. The device features protection class III and can be ceiling-mounted, with a 121 mm diameter hole (in plasterboard). Compliant with the EN 60598-1 standard and its specific provisions.
LINEALIGHT
PROJECTOR LIGHT
OUTDOOR LIGHTING
Single emission projectors for outdoor application. The warm white LED light source with a flood light distribution is composed of 1 arrayled LEDs. The luminaire body is made of aisi 316 steel and features a steel finish, processed by means of electropolishing; the diffuser is made of extra clear glass - tempered with a silk-screening treatment. The ingress protection degree is IP68,IK10.
VDA
CONTROL SYSTEM
INDOOR LIGHTING

The Dimmer (MOS-FET technology) 4 x 200 W ModBus is an expansion module connected and controlled by the ICU Room Controller of Micromaster System, the up-to-date generation of Intelligent Room Management System designed to provide fully integrated automation for hospitality industry. The Dimmer 4 x 200W is a 4-channel dimmer used to turn On/Off lights by “one touch” mode or to vary light intensity by “dimming touch” mode. If required, the modular construction of Micromaster System allows to easily add such expansions also in a later time.

XAL
ADJUSTABLE DOWNLIGHT
INDOOR LIGHTING

Round recessed adjustable spotlight in die-cast aluminium housing, surface matt silver; 360° rotatable and 30° tiltable. Installation without tools in mounting set due to patented ball catch system; round installation housing; with trim traffic white; suitable for ceiling thickness of 2-25 mm; passive cooling of the LEDs through improved heat sink geometry with COB (Chip on Board) technology for maximum efficiency; no appearance of multiple shadows;
