LED LINEAR
INGROUND LINEAR LIGHT
OUTDOOR LIGHTING
VARIOLED OCEANOS IQW HYDRA HD12/1020-30D IP67

24 V, IP67 protected and IK10 certified, linear LED luminaire for indoor and outdoor in-ground installation. Suitable for installation into roads and parking lots according to EN 60598-2-13. To be walked on and traversed by vehicles with air filled tires (including trucks used for delivery). Polyurethane encapsulation offering a premium water proof sealing (values), UV resistance (no coloration or increase of absorption) chemical stability against urban gazes and protection against abrasion. Stainless Steel V4A housing delivered with male/female IP67 connectors. Available either with an opal top layer or transluscent with an internal 10° and 30° lenses for wall grazing. Light source assembled using state of the art automated Reel-to-Reel (R2R) production process supporting LED Linear™ Tj Away thin flexible circuit board technology.

Specification
Power 12W/M
Color Temperature TW 2200K - 4000K
Light Source Type LED
Lumen Output 970LM/M
Finishing WHITE
IP Rating IP67
Color Rendering CRI 95
Driver ON/OFF DRIVER
See More
IGUZZINI
RECESSED DOWNLIGHT
INDOOR LIGHTING
Fixed round mini-recessed luminaire with contact frame. The LED is set back to minimize direct glare. The recessed body is made of machined aluminium and the inside of the ring of thermoplastic available in a range of painted and metallised finishes. PMMA - medium (25°) high resolution optic lens.
LINEALIGHT
INGROUND FOOT LIGHT
OUTDOOR LIGHTING

Single emission uplights for outdoor application. The warm white LED light source with a radial mono-directional emission light distribution is composed of 1 arrayled LEDs. Luminaire body is made of aluminium and features a grey ral 9006 finish, processed by means of coating. The ingress protection degree is IP67; IK10

IGUZZINI
INGROUND LINEAR LIGHT
OUTDOOR LIGHTING

Ground- and wall-recessed using the outer casing, to be ordered separately. For ground installation a drainage channel must be created or gravel inserted for drainage under the outer casing before installation, to guarantee the degree of protection stated. For ceiling-mounting with plasterboard panels (1-30 mm thick), make the preparation openings as indicated in the instructions sheet and use the accessory with code X013 (kit containing steel cables with reinforcement plates).

FLOS
BOLLARD
OUTDOOR LIGHTING
100-240V power supply included. Ready for installation on solid surface. Each luminaire is equipped with 200 mm cable for connection inside the luminaire body. Reccomended connection wit a 2 way terminal block 4 poles IP68 H2O Stop, to be ordered separately.
