LIGMAN
WALL LIGHT
INDOOR LIGHTING
NYB-30001-O-W30

Luminaire made of die-cast aluminium end-caps and extruded aluminium profile with powder coating. Single cable entry. Stainless steel fasteners in grade 316. PMMA diffuser with Opal (UGR <19) and micro prismatic (UGR <13) options for better glare control. Up and down light distribution options- Passive thermal management, integral control gear. Wireless control available through Bluetooth connection. Daylight and occupancy sensor options. Emergency module (1 or 3 hours) is available upon request with 3 options (BASIC, SELF-TEST, PRODALI). IP20.

Specification
Power 11W
Color Temperature 3000K
Light Source Type LED
Lumen Output 871LM
Finishing ALUMINIUM
IP Rating IP20
Color Rendering CRI80
Driver ON/OFF DRIVER
See More
ELR
ADJUSTABLE DOWNLIGHT
INDOOR LIGHTING
Compatible with 35 and 50 series LED modules. Colour temperature options 2700K,3000K, 4000K, 5000K, tuneWHITE, WarmDim. Colour rendering index 85 or 95. Up to 50,000 hours L80 lamp life with LM80 tested LED chip packages. Beam pattern options ClassicPRO 12, 20, 35, 60. Luminous flux 335lm to 1500lm depending on LED module.
LINEALIGHT
RECESSED DOWNLIGHT
INDOOR LIGHTING
Single emission downlights for indoor application. The warm white LED light source with a wide flood light distribution is composed of 1 arrayled LEDs. The device body is made of die-cast aluminium en ab - 46100 and features a embossed black ral 9005 finish, processed by means of powder coating. The ingress protection degree is IP40; the total weight is of 0.150 kg. The power supply driver is not provided and is to be ordered separately. The power supply cable is included and features a 0.15 m length. The device features protection class III and can be ceiling-mounted, with a 60 mm diameter hole (in plasterboard) with an outer casing, code 89374 (for concrete or masonry). Compliant with the EN 60598-1 standard and its specific provisions.
CDN LIGHTING
RECESSED DOWNLIGHT
INDOOR LIGHTING


LINEALIGHT
ADJUSTABLE DOWNLIGHT
INDOOR LIGHTING

Single emission recessed downlights for indoor application. The super warm white LED light source with a flood light distribution is composed of 1 arrayled LEDs with CCT of 2700 K and a CRI 90; the source luminous flux is 715 lm, with a 110.0 lm/W nominal luminous efficacy.The device body is made of die-cast aluminium en ab - 46100 and features a white finish, processed by means of powder coating. The ingress protection degree is IP40; the total weight is of 0.15 kg.
