Double emission wall lights for outdoor application. The warm white LED light source with a extra wide flood light distribution is composed of 2 arrayled LEDs. The device body is made of die-cast aluminium en ab - 46100 and features a embossed white ral 9003 finish, processed by means of open pore anodizing + powder coating; the diffuser is made of extra clear glass - tempered with a silk-screening treatment. The ingress protection degree is IP65; the total weight is of 1.5 kg. The device features protection class I and can be wall lights-mounted. Compliant with the EN 60598-1 standard and its specific provisions.

Round recessed downlight made of die-cast aluminium with white powder-coating finish (RAL 9016) and white reflector; ON-OFF Driver; System Power 9W; measurement Ø85mm; ceiling cutout of Ø75mm with a narrow mounting trim; luminaire's weight is approximately 220g; CCT 2700K with a System luminous flux of 550lm; high color rendering at an index of CRI90; after a lifetime of 50000h min. 80% of the luminous flux with energy efficient CITIZEN LED Chips; 5 years warranty; beam characteristic with 35° beam angle; lighting perfectly suitable for reading, writing as well as computer and control work with UGR<19; degree of housing protection IP20 (LED Module IP54) on the visible part of the product once installed; light source replaceable by a qualified electrician; driver replaceable by a qualified electrician

The Energi Savr Node (ESN) family is a group ofmodular products for the control of lighting loads. 0-10 V/switching power module can be used in anAthena system.• Includes QS link for seamless integration of lightsand controls.• Auto sink and source capability for 0 –10 V- outputs.• Buttons on the module provide override control.• LEDs on the module provide diagnostic information.• 0-10 V/switching power module can be used for0 –10 V- and switching applications only.

Die cast aluminium housing body, powder coated with pretreatment for indoor outdoor use. Up and down cover sheet can be laser cut to other drawings o
