TA5 + LED Module/ M4P3-0301513A-TA5-BB

Round recessed mounted downlight made of die-cast aluminium with black powder-coating finish (RAL 9005) and black reflector; LED 13W; measurement Ø85mm; ceiling cutout of Ø75mm with a narrow mounting trim; rotation 355°and pivot max. 30°; CCT 3000K with a System Luminous Flux of 1000lm high color rendering at an index of CRI97; SDCM: 2; after a lifetime of 50000h L80B10 min. 80% of the luminous flux with energy efficient BRIDGELUX LED Chips; 5 years warrant

Side bend dot-free flexible light, cuttable every 50mm at site. Updated with low wattage high lumen LED series. Available 4 different wattage variations. Indoor usage only, custom length max.5m per roll, connectable 10m per circuit

With 18 linearly arranged highperformance LEDs, the robust stainless steel recessed spotlight with its above-average high quality creates a wide light distribution that homogeneously illuminates the entire surface of the water in large public swimming pools or hotel pools. It is also used for marking lines in sports pools. Options ranging from cool to neutral to warm white, blue and RGB are available as colour temperatures. Thanks to the swivelling capability of the LED unit during production, the light cone can be directed onto the floor to achieve better illumination and minimise glare.

Spotlight designed to use LED lamps and a Medium optic. The optical assembly and base is made of EN1706AC 46100LF aluminium alloy and subjected to a multi-step, pre-treatment process, in which the main phases are degreasing, fluorozirconation (a protective surface film) and sealing (with a nano-structured silane layer). The following painting stage consists of a primer and a liquid acrylic paint, cured at 150°C, with a high level of weather and UV ray resistance. 5 mm thick tempered sodium-calcium closing glass. Double adjustability allows a 360° rotation about the vertical axis and 90° tilting relative to the horizontal plane. The ingress protection degree is IP66,IK07.
