Light source: High density, LM80 proved. Process & Material: High light transmittance, environmental silicone material, integrated extrusion molding technology. Optical Design: Unique optical light distribution structure design, uniform lighting surface and no shadow. Appearance Design:Super small model, compact and simple, unique design. Product Certification: CE、ROHS. Environmental Features: Resistance to saline solutions, acids & alkali, corrosive gases and UV. Working/Storage Temperature: Ta:-25~55℃ / 0℃～60℃. Application:Interior outline, Furniture supporting lighting. Indoor 3-year warranty, working life ≥ 36000 hours.

Prologe 145 double directional surface mount luminaire in steel sheet material and black powder coated finishing.

Dimension : L280mm x W140mm x H155mm

Cygnus came about due to demand for a track fitting following the style and theme of all our designs, ie: simple, strong and well finished. Cygnus utilises the LEDil reflectors for a perfect and reliable light shape. The extruded aluminium housing and is available in our full range of finishes. Cygnus is supplied as standard with a Tridonic in track adapter, so the control gear is integral. Other adapters are available, but should be specified to the factory.

Body made of AISI 316L monoblock stainless steel. Absence of screws (the luminaire is fixed to the recessing box with OR rings). Recessing box in polypropylene. Mechanical resistance of diffusor IK 08 Maximum load capacity 500 Kg. This luminaire contains built-in LED modules. In case of damage or malfunction please contact the manufacturer to receive additional instructions on how to replace and relative spare parts to order. The LED modules cannot be handled in the luminaire by the end user. This product contains a light source of energy efficiency class: F. LED modules are engineered accordingly to the existing regulations of Lumen Maintenance (LM80) and Technical Memorandum (TM21), where uniformity and quality of the light is 70,000 hours referred to L80 B10 Ta 25 ° C (50,000 hours referable to L80 B10 Ta 40°C). Lifespan of the luminaire min. 50,000 hours at 40°C. Performance Ambient temperature Tq 25°C. Operating ambient temperature range is from -20°C to +50°C. Storage temperature range from -20°C to +60°C.
