Rectangular recessed multi-downlight made of die-cast aluminium; installation without tools in mounting set due to patented ball catch system; rectangular installation housing; with trim traffic white; suitable for ceiling thickness of 2-25 mm; equipped with three wide flood round light elements; symmetrical light distribution with precise radiation characteristic, beam angle 72°; high quality reflector with micro-faceted, aluminum-vaporised surface; chrome reflector; passive cooling of the LEDs through improved heat sink geometry; light colour 3000K; binning initial MacAdam ≤ 3 SDCM; CRI ≥ 90; min. 90% of luminous flux after 50000 operating hours; energyefficient high power LEDs with very good colour rendering; degree of protection IP20; PC2; incl. DALI-2 converter; through wiring connection box, 3-pole or 5-pole, available as an accessory; accessories are listed separately; light source not replaceable; control gear replaceable by an authorized professional; clank-free

Luminaire made of aluminium alloy, aluminium and stainless steel. Safety glass, antireflection-coated. Silicone gasket. Reflector made of pure anodised aluminium. Toolless closure. For pole top 76 mm. Inner diameter of the pole min.62 max.70 mm. Slip fitter insert depth 90 mm. Connecting cable X05BQ-F 4 1 Cable length 8 m LED power supply unit 220-240 V x 050-60 Hz DC 176-264 V Dimmable 1-10 V A basic isolation exists between power cable and control line. Luminaire Protection class IP 66. Dust-tight and protection against strong water jets. Safety class II 2. Impact strength IK08 Protection against mechanical impacts 5 joule, r Safety mark, c Conformity mark. Wind catching area 0.03 m.

Single emission downlights for indoor application. The warm white LED light source with a flood light distribution is composed of 1 powerled LEDs. The device body is made of aluminium 6026 and features a embossed black ral 9005 finish, processed by means of powder coating; the diffuser is made of uv resistant polycarbonate. The ingress protection degree is IP44; the total weight is of 0.078 kg. The power supply driver is notprovided and is to be ordered separately. The power supply cable is included and features a 0.170 m length. The device features protection class III and can be ceiling-mounted, with a 29 mm diameter hole (in plasterboard) with an outer casing, code 99847 (for concrete or masonry). Compliant with the EN 60598-1 standard and its specific provisions

The Star series is available in recessed luminaires that meet the needs of different application areas: from the fixed version with springs, to the anti-glare, up to the adjustable.

These products are therefore ideal for architectures, cabinets and shelves.
