81687W08
Single emission lines for outdoor application. The warm white LED light source with a flood light distribution is composed of 12 powerled LEDs. The device body is made of aluminium 6060 and features a anodised aluminum finish, processed by means of 20 µm anodizing; the diffuser is made of extra clear glass - tempered with a silk-screening treatment. The ingress protection degree is IP68; the total weight is of 1.020 kg. The power supply cable is included and features a 0.250 m length. The device features protection class II and can be floor-mounted with an outer casing, code 99762 (for concrete or masonry). Compliant with the EN 60598-1 standard and its specific provisions.
Specification
Power 10.1W
Color Temperature 3000K
Light Source Type LED
Lumen Output 1037LM
Finishing ANODISED ALUMINUM
IP Rating IP68
Color Rendering CRI 80
Driver ON/OFF DRIVER
See More
WE-EF
BOLLARD
OUTDOOR LIGHTING
IP66. IK10. Marine-grade, all-aluminium construction. 5CE superior corrosion protection including PCS hardware. Polycarbonate lens. Silicone CCG® Controlled Compression Gasket. Luminaire is factory-sealed and does not need to be opened during installation. Integral EC electronic converter in thermally-separated compartment. Advanced thermal management protects LEDs while optimising lumens output. CAD-optimised optics for superior illumination and glare control.
DALITEK
CONTROL SYSTEM
CONTROL SYSTEM

220VAC single phase power input, 1 channel DALI DIN-Rail control signal output,1 channel switch output,20A/CH, each channel supports 64 DALI address(Support mixed use of DT6 and DT8)

SPARK
RECESSED DOWNLIGHT
INDOOR LIGHTING

Recessed fixed downlight made of aluminium housing with white powder coated finish. Inner reflector available in mirror chrome, white and black color. Cut-out Ø150mm. For indoor use. IP20.

SPARK
INGROUND UPLIGHT
OUTDOOR LIGHTING
